TECHNICAL SPECIFICATION
BASIC FEATURES
| Rated capacity | 25 L |
| Installation | Vertical |
| Color | White Champagne Gold |
| Color options | Ivory Champagne Gold |
| Ideal for | Bathroom , High rise buildings |
| Temperature setting | Digital temperature display |
| Digital temperature display | Yes |
| Whirl flow technology | Yes |
PERFORMANCE FEATURES
| Rated pressure | 0.8 MPa |
| Standing loss in kWh / 24 h / 45 C | 0.562 kWh |
| Mixing factor maximum ( % ) | 30% |
| Reheating time in minutes to raise 50 C | 40 minutes |
POWER DETAILS
| Rated Power Input | 2000 W |
| Rated input current | 8.7 Ampere |
| BEE rating | 4 Star |
| Energy efficiency feature | Energy saving high density PUF insulation |
| Rated voltage | 230 V, 1 Phase, 50 Hz AC |
DIMENSIONS WEIGHT
| Height | 560 mm |
| Width | 413 mm |
| Packing dimensions LxWxH (cm) | 46.8 cm x 45.5 cm x 70.5 cm |
| Weight when empty | 15.2 kg |
| Length | 310 mm |
TANK FEATURES
| Heating element | No heating element |
| Tank material | Made of ultra thick super cold rolled steel plates |
| Tank finish and coating | Feroglas dry powder coating technology |
| Extreme hard water resistance | Yes |
| Anode rod rust and corrosion resistance | Heavy duty magnesium anode rod with steel core to protect enamelled tank from rust and corrosion |
WARRANTY GUARANTEE
| Tank Warranty | 7 year |
| Body and electrical components Warranty | 2 Year |
SALES PACKAGE (S)
| Net contents | 1 N Storage Electric Water Heater ,1 N User Manual,1 N Multifunction Safety Valve , 1 N Mounting Kit ,1 N Remote Controller, 2 N Fasteners & 2 N Flexible Pipes |
SAFETY FEATURES
| Thermostat | Yes |
| Thermal cut off | Yes |
| Multifunctional safety valve | Yes |
| Geyser protection from water splash | IPX4 technology to protect electrical parts from water splash, No |
| Electrical safety | Shock safe plug |
